Balcrank Electric Diaphragm Pump Drum Package
Balcrank Electric Diaphragm Pump Drum Package 2

Balcrank Closed System Electric Diaphragm Pump Drum Packages

Balcrank's Closed System Electric Diaphragm Pump Drum Packages features a compact design mounting bracket and a heavy-duty cart, which easily holds and rolls up to 55 gallon drum. Large semi-pneumatic tires - allow for easy maneuvering of cart. Large non-marking rear caster - built in break for safe and secure dispensing.

Call us TODAY at 727-835-0671 or
Toll Free at 800-761-4298

Get A Free Quote!

Model#:
1210-046P - 120 V AC Non-metered, Manual Nozzle
1210-048P - 120 V AC Non-metered, Auto Nozzle
1210-049P - 120 V AC Metered, Auto Nozzle
1210-053P - 12 V DC Metered, Auto Nozzle
Includes:
  • 8570-006, 6' x 3/4" Suction hose.
  • 8561-012, 12' x 3/4" Discharge hose.
  • 4530-054, Drip tray
  • 4320-007, Drum cart 55 gal for DEF.
  • 4530-065, Side mount bracket.

    Options:
  • 3120-116, Meter DR style for DEF.
  • 1200-020, 120 V AC Electric diaphragm pump.
  • 1200-021, 12 V DC Electric diaphragm pump.
  • 3340-012, Auto nozzle, stainless steel.
  • 3340-015, Manual nozzle, polyethylene.

Technical Data DATA 120 V AC
(1200-020)		 DATA 12 V DC
(1200-021)
Max. Free Flow 8.5 GPM 9.5 GPM
Working Pressure 23 psi (1.6 bar) 23 psi (1.6 bar)
Power 120 V AC 12 V DC
Wetted materials Stainless Steel, Viton, PPE Stainless Steel, Viton, PPE



CLOSED system containers have a valve coupling system that seals the container opening on drums and totes (IBC) to prevent dirt, debris, bugs, etc., from entering the container and contaminating the diesel exhaust fluid. Liquid in container system is sealed and secure, throughout container life cycle.

For closed systems, use Reusable Poly Valve (RPV) or Reusable Stainless Valve (RSV) systems accessories. RSV and RPV components are interchangeable.

NOTE: DEF Packages do not included coupler systems. Order Seperately. You Must choose a coupler kit to create a complete system for your distribution needs.
Closed System Coupler Components
